ABB SYNCHROTACT 6302
-
Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
Mail： 3598571032@qq.com
Phone/Wechat/Whatsapp：+86 15339539190
-
Details
1. Product Overview
ABB SYNCHROTACT6302 is a high-precision synchronization unit engineered for grid connection and parallel operation of generators, turbines, and large rotating machinery. It automatically matches key parameters (voltage, frequency, phase angle) between the equipment and the power grid, ensuring smooth, shock-free synchronization to avoid equipment damage and grid disturbances. Compliant with IEC 61000-6-2 (EMC) and IEEE 1547 (grid interconnection) standards, it’s a core component for power plants, industrial power systems (CHP), and renewable energy (solar/wind) plants.
2. Key Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | ABB SYNCHROTACT6302 |
| Product Type | Generator/Turbine Synchronization Unit |
| Synchronization Parameters | Voltage (±0.1% accuracy), Frequency (±0.01 Hz accuracy), Phase Angle (±0.5° accuracy) |
| Input Signals | 3-phase AC voltage (100V/220V), Frequency (50/60 Hz), Speed Pulse (from tachometer) |
| Output Signals | Relay outputs (synchronization command, alarm), 4–20 mA (analog feedback for parameters) |
| Communication Protocols | Modbus RTU/TCP, Profinet, IEC 61850 |
| Power Supply | 24V DC (±15% tolerance) / 110/220V AC |
| Operating Temperature | -25°C to +70°C |
| Protection Class | IP20 (panel/cabinet mounting) |
| Certifications | CE, UL, CSA, IECEx |
| Dimensions (W×H×D) | 144mm × 100mm × 180mm (5.67in × 3.94in × 7.09in) |
| Weight | Approx. 0.8kg (1.76lb) |
3. Core Application Scenarios
3.1 Thermal/Hydro Power Plants
Synchronizes steam/hydro generators with the main grid during startup or load adjustment, preventing voltage/frequency fluctuations that affect grid stability.
Reduces mechanical stress on turbine-generator shafts by ensuring zero phase difference during connection.
Enables parallel operation of on-site generators (diesel/gas-fired) with the public grid, optimizing energy use (e.g., switching to grid power during low production hours).
Provides fast re-synchronization after grid outages to restore critical industrial loads (e.g., manufacturing lines, data centers) within seconds.
3.3 Renewable Energy Plants
Synchronizes solar/wind inverters or battery energy storage systems (BESS) with the grid, complying with IEEE 1547 standards for stable renewable energy integration.
Compensates for intermittent renewable energy output by adjusting synchronization timing to match grid demand.
4. Core Features
High-Precision Matching: ±0.1% voltage, ±0.01 Hz frequency accuracy ensures "zero-impact" grid connection, protecting expensive rotating machinery.
Multi-Scenario Adaptability: Supports 50/60 Hz grids and 3-phase input voltages, fitting global power system standards.
Smart Monitoring & Alarm: Real-time display of synchronization parameters; triggers alarms for voltage/frequency deviations to prevent faults.
Seamless Grid Integration: Compatible with Modbus/IEC 61850, enabling remote control and data logging via plant DCS/SCADA systems.
