Introduction

Basic Product Information

Full Model: H92B0PCR0H00

Brand: FOXBORO (Schneider Electric)

Series: H92 I/A Series DCS Module

Product Type: Analog Input Signal Acquisition Card

Production Status: Officially Discontinued

Origin: United States

Warranty: 12 months for all units

Stock Status: Refurbished tested / unused surplus available

Delivery: Worldwide express delivery, 3-7 working days lead time

Core Electrical Specifications

Power Supply: Backplane 24VDC power supply

Field Input Signal: 4–20mA analog current signal, HART protocol support

Channel Design: Multi-channel isolated signal input

Isolation Strength: 3750VDC channel-to-backplane isolation

ESD Protection: 4kV anti-static protection

Operating Temperature: 0℃ ~ +50℃ (cabinet installation)

Storage Temperature: -20℃ ~ +70℃

Signal Accuracy: ±0.1% full scale

Communication: I/A Series system backplane bus, HART pass-through for remote transmitter diagnosis

Mechanical Parameters

Mounting: Plug-in installation for standard I/A Series DCS carrier baseplate

Dimension: Compact H-series standard module size

Net Weight: 160g

Cooling: Natural air convection

Certification: CE industrial safety certification

Key Product Features

High isolation design eliminates electromagnetic interference in harsh factory environments

Native HART communication supports remote transmitter parameter reading & calibration

Real-time hardware fault LED indicators for fast on-site troubleshooting

Hot-swappable compatible design for non-stop system maintenance

Wide temperature range adapts power plant, oil & gas, chemical production workshops

Full compatibility with FCP270, FCP280 I/A Series process controllers

Rigorous aging & load testing before shipment for stable long-term operation

Industrial Application Scenarios

Thermal power plant boiler & turbine DCS control systems

Petrochemical refinery crude processing unit monitoring

Natural gas pipeline pressure & flow signal collection

Pharmaceutical factory automated process control

Water treatment plant analog signal acquisition

Legacy Foxboro I/A Series DCS equipment spare replacement

Compatible Matching Components

FCP270 / FCP280 I/A Series field control processors

RH92 series DCS baseplate chassis

Foxboro H92 series terminal block assemblies

Other H92 family I/O modules for I/A Series system expansion

FAQ

Q1: Is FOXBORO H92B0PCR0H00 still manufactured?

Q2: Which DCS system matches H92B0PCR0H00?

Q3: Does refurbished H92B0PCR0H00 come with quality test documents?

Q4: Can H92B0PCR0H00 be shipped internationally?
