The IS200TAMBH1ABB is a core component of the GE Speedtronic Mark VI series, positioned as a Turbine Alarm Module. It is mainly used for safety monitoring and alarm signal processing in industrial turbine systems. The detailed information is as follows:

1. Basic Information

Brand: GE (General Electric)

Model: IS200TAMBH1ABB

Product Series: Speedtronic Mark VI (GE's classic turbine control system series)

Function Positioning: Turbine Alarm Module (abbreviated as TAM)

Core Function: Real-time monitoring of turbine operating status, collection and processing of various alarm signals, and transmission of data to the main control system to ensure safe operation of equipment

2. Main Technical Specifications

(The parameters are sorted out based on the general specifications of the GE Mark VI system and official technical documents of similar modules. For specific details, please refer to the original factory data sheet.)

Power Supply Specification: Backplane power supply with a standard voltage of +5V DC and ±15V DC (meeting the stability requirements of industrial-grade power supplies)

Operating Environment:

Operating Temperature: 0°C ~ 65°C (suitable for high-temperature/stable industrial scenarios such as power plants and chemical plants)

Storage Temperature: -40°C ~ 85°C (meeting the requirements of long-term storage and transportation environments)

Humidity Range: 5% ~ 95% RH (non-condensing, preventing moisture from affecting the circuit)

Interface Type:

Input: Digital Input (DI), used to connect alarm trigger signals from sensors and equipment (such as excessive temperature, abnormal pressure, etc.)

Output: Digital Output (DO), used to drive alarm indicator lights and interlock control signals

Communication: Integrated backplane communication interface for real-time data interaction with the main controller of the Mark VI system

Status Indication: Equipped with multiple groups of LED indicator lights, which respectively display the overall operating status of the module (normal/fault) and the signal status of each input channel (activated/inactivated)

Physical Specifications:

Dimensions: Conforming to the standard board size of the Mark VI series, approximately 3.4 inches × 6.4 inches (facilitating rack integration and installation)

Weight: Approximately 0.9 kg (lightweight design, without increasing the overall load of the system)

3. Core Functional Features

Real-time Alarm Response: Processes alarm input signals in milliseconds, quickly identifies abnormal statuses, and avoids safety risks caused by delays in equipment operation

Multi-channel Monitoring: Supports simultaneous access of multiple alarm signals (the specific number of channels should refer to the original factory data sheet), covering key operating parameters of the turbine (such as speed, vibration, oil temperature, etc.)

High-reliability Design: Industrial-grade circuit protection, resistant to electromagnetic interference (EMI) and voltage fluctuations, suitable for harsh industrial environments such as power plants and petrochemical facilities

Intuitive Status Feedback: Clearly distinguishes statuses such as "normal module operation", "channel alarm", and "communication fault" through LED lights, facilitating on-site maintenance personnel to quickly troubleshoot problems

Seamless System Integration: Can be directly installed in the standard rack of the Mark VI system and work in coordination with control modules of the same series (such as speed control modules and load regulation modules) without additional adaptation

4. Typical Application Scenarios

Power Industry: Safety monitoring of gas turbines and steam turbines (e.g., thermal power plants, combined cycle power plants), real-time alarming of risks such as abnormal turbine speed and excessive bearing temperature

Industrial Drive Field: Monitoring of operating status of large rotating equipment (e.g., compressors, industrial pumps) to ensure stable operation of equipment under high load

Petrochemical Industry: Protection systems for key power equipment (e.g., fans driven by steam turbines) in oil refining and chemical production, preventing production interruptions caused by equipment failures

Other Scenarios with High Reliability Requirements: Industrial automation systems that require real-time alarming and safety interlocking (e.g., metallurgy, energy recovery equipment)

5. Ways to Obtain Official Data Sheets

To obtain complete original factory information such as electrical parameters, wiring diagrams, and installation specifications, you can use the following methods:

GE Official Platform: Log in to the GE Digital or GE Power official website, search for the model "IS200TAMBH1ABB" in the "Industrial Automation" section, and download the corresponding technical documents (some require registration of an enterprise account)

GE Customer Service/Agents: Contact the local GE industrial automation department or authorized agents, and apply for the data sheet after providing the model (suitable for enterprise users to obtain customized support)

Industrial Sp   are Parts Platforms: Some formal industrial electronic component websites (e.g., RS Components, Digikey, etc.) provide authorized data sheet download services
