GE 369-HI-R-B-O-P-H-E Digital Relay
-
Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
Mail： 3598571032@qq.com
Phone/Wechat/Whatsapp：+86 15339539190
-
Details
1. Product Overview
GE 369-HI-R-B-O-P-H-E is a flagship motor management digital relay under GE's Multilin series, specifically designed for full-lifecycle protection, precise control, and intelligent monitoring of industrial motors. With a microprocessor as its core and a modular architecture, it can real-time collect the electrical and mechanical status of motors. Through customized protection logic, it minimizes downtime risks, extends motor service life, and serves as a core safety unit in industrial automation systems.
2. Key Technical Specifications
1. Electrical Specifications
- Control Power Supply: 50-300 VDC or 60-264 VAC (compatible with global industrial power supply standards)
- Current Input: Phase current 1A/5A (secondary CT input); ground current detection frequency 20-100Hz
- Temperature Monitoring: 12 independent Resistance Temperature Detector (RTD) inputs, compatible with types such as 100Ω Pt, 100Ω Ni, 120Ω Ni, and 10Ω Cu
- Overload Capacity: Withstands 150% overload for 1 minute (handles motor startup inrush current)
2. Communication & Integration
- Interfaces: 1 front-panel RS232 port, 3 rear-panel RS485 ports; Ethernet expansion supported for selected models
- Protocols: Supports Modbus RTU/TCP and DNP3 protocols, enabling seamless integration with SCADA (Supervisory Control and Data Acquisition)/DCS (Distributed Control Systems)
- Programmability: Built-in soft PLC (Programmable Logic Controller), supporting custom logic and protection curve configuration
3. Environmental & Physical Characteristics
- Operating Environment: Temperature -40°C to +60°C, relative humidity 95% (non-condensing)
- Storage Environment: Temperature -40°C to +80°C
- Installation Method: Standard DIN rail mounting; metal flame-retardant enclosure, IP30 protection rating for cabinet-mounted installation
- Dimensions & Weight: Approximately 292×140×216 mm (H×W×D); unit weight approximately 3.6 kg
4. Certifications & Safety
- Certifications: Compliant with CE, UL, and CSA certifications; IEC 61850 communication standard compatibility available as an option for selected models
- EMC (Electromagnetic Compatibility): Compliant with EN 61000 standard (resistant to strong electromagnetic fields and high-current interference)
3. Core Functions & Advantages
1. Comprehensive Protection
- Electrical Protection: 12 types of protection functions including overcurrent, undercurrent, overvoltage, undervoltage, short circuit, and ground fault
- Thermal Protection: Combines I²t thermal modeling (Function 49) with direct RTD temperature measurement to prevent motor burnout due to overheating
- Mechanical Protection: Equipped with jam detection, reverse rotation alarm, and bearing temperature anomaly early warning functions
- Customized Protection: 8 programmable protection curves, suitable for different motor types such as induction motors and synchronous motors
2. Intelligent Monitoring & Diagnosis
- Real-Time Data: Monitors over 20 parameters including current, voltage, power, frequency, and energy consumption (kWh/MWh)
- Event Tracing: Stores 512 historical events (including fault type, time, and waveform data), supporting waveform capture of 16 cycles before tripping
- Health Report: Generates motor health scores, predicts maintenance cycles, and reduces unplanned downtime
3. Flexible Control & Integration
- Control Modes: Supports local keypad control, remote communication control, and logical linkage control
- Expansion Capability: Modular I/O (Input/Output) design, allowing addition of analog/digital modules to meet customized requirements
- HMI (Human-Machine Interface): 40-character LCD (Liquid Crystal Display) with navigation keys, supporting on-site parameter configuration and fault query
4. Operating Principle
Operates based on a closed-loop mechanism of "Signal Acquisition - Logic Judgment - Protection Execution - Data Feedback":
- Signal Acquisition: Collects electrical and temperature signals via CT (Current Transformer), PT (Potential Transformer), and RTD, then converts them into digital quantities through A/D (Analog-to-Digital) converter;
- Data Processing: The microprocessor compares real-time data with preset thresholds to identify abnormal conditions such as overcurrent and overtemperature;
- Protection Execution: Fault trigger response time is only 0.1 ms, cutting off motor power supply or issuing an alarm signal, while initiating waveform capture and event recording;
- Data Feedback: Uploads fault data and real-time parameters to the SCADA system via communication protocols, supporting remote reset and parameter adjustment.
5 . Sizing & Services
- Compatible Motors: AC induction/synchronous motors with rated voltage ≤10 kV and rated current ≤630 A
- Value-Added Services: Provides EnerVista 369 configuration software, supporting remote debugging, data export, and firmware update
- Warranty Services: 2-year global warranty, with on-site maintenance and technical support provided by GE's global service network
Many products have not been listed yet. For more products, please contact usIf the product model is inconsistent with the displayed image, the model shall prevail. Please contact us for specific product images, and we will arrange for photos to be taken and confirmed in the warehouse
We have 16 shared warehouses worldwide, so sometimes it may take several hours to accurately return to you. We apologize for any inconvenience caused. Of course, we will respond to your concerns as soon as possible.
